Construction Heavy Duty Q235 Steel 1M 1.5M 2M 3M 3.6M Scaffolding Shoring Formwork Soldier Beam
The Formwork Scaffolding Beam Soldier is a modular support system designed for concrete pouring in construction projects, widely used in high-rise buildings, bridges, tunnels, and large-scale infrastructure. Composed of high-strength beams and vertical soldiers (columns), this system provides stable and adjustable support for formwork and scaffolding, ensuring both safety and efficiency during construction.
The Formwork Scaffolding Beam Soldier is a modular support system designed for concrete pouring in construction projects, widely used in high-rise buildings, bridges, tunnels, and large-scale infrastructure. Composed of high-strength beams and vertical soldiers (columns), this system provides stable and adjustable support for formwork and scaffolding, ensuring both safety and efficiency during construction.
| 180*220MM | ||||||
| code | length | Surface Treatment | weight/kg | Materil | brand | standard |
| UTM-SL-100-1 | 1000mm | paint/galvanizing | 20.23 | Q235 | UTM | EN74 BS1139 AS1576 |
| UTM-SL-100-1.5 | 1500mm | 27.81 | ||||
| UTM-SL-100-2 | 2000mm | 36.12 | ||||
| UTM-SL-100-3 | 3000mm | 52.13 | ||||
| UTM-SL-100-3.6 | 3600mm | 61.7 |
Key Features
High Strength & Durability
Made from premium steel or aluminum alloy, offering exceptional compression and bending resistance with a load capacity of up to XX tons/m² (varies by model).
Anti-corrosion treatment (e.g., hot-dip galvanizing or coating) for durability in harsh environments.
Modular Design
Standardized beams, soldiers, and connectors enable quick assembly and disassembly, reducing labor and time costs.
Adjustable height (e.g., 0.5m–5m) and span to accommodate different floor heights and structural requirements.
Safety & Reliability
Integrated locking mechanisms and anti-slip design ensure secure connections, minimizing collapse risks.
Complies with international safety standards (e.g., EN 12811, OSHA) and third-party certifications.
Versatile Compatibility
Compatible with various formwork systems (wood, steel, aluminum) and scaffolding types, supporting horizontal and vertical extensions.
Optional accessories (e.g., swivel bases, diagonal braces) for complex terrains and irregular structures.
Concrete Slabs/Walls: Provides uniform support to horizontal formwork, preventing sagging.
Bridge Piers: Secures cylindrical formwork with vertical soldiers for precise alignment.
Large Cantilever Structures: Reinforced beams and diagonal braces ensure stability for long-span overhangs.
